Thermal Commercial Door and Frame
The thermal commercial door and frame is a ground floor treatment system developed for commercial newbuild and refurbishment projects.
It is perfect for high-traffic environments such as schools and commercial buildings, particularly where enhanced regulations and stricter security standards are required. Robust and cost-effective, the system also exceeds current building regulation requirements in thermal efficiency.
Features and benefits
With a focus on thermal insulation, the door and frame system is a high-performance solution that integrates seamlessly with other Kestrel systems, making it adaptable to a broad range of contemporary applications.
- Thermal efficiency: High thermal performance with potential U values of 1.6W/m2K* for both single and double doors.
- All-in-one solution: Full compatibility with the Kestrel thermal framing and window systems for a uniform design.
- Slimline profiles: Minimise sight-lines while maintaining excellent thermal insulation all year round.
- Multiple PAS 24 configurations available: Single and double door with multipoint or 2 x single point lock options, as well as single door access control and single and double door panic and escape hardware.
*Based on standard Ug 1.0 W/m2 k DGU, Ultimate spacer as per Approved Document L requirements. Values achieved using a centre pane unit of 1.0W/m2K.
Design options
With a triple glazing option for outstanding thermal insulation and a range of opening configurations, the thermal commercial door and frame system is an ideal solution for energy-efficient buildings that demand both durability and security.
- Glazing options: Double or triple glazing, with insulating glass units and infill panels of up to 47 mm on the door and 32mm on the framing.
- Multiple opening types: Doors can be specified and configured as inward or outward-opening, with centre pivot, auto swing or auto slide options.
- Range of stiles, rails and thresholds: Options include EA compliant thresholds and anti-finger-trap stile.
- Surface finishes: Mill finish, etched and anodised options are available with single and dual-colour surfaces to suit every design requirement.
| Application | Commercial, new build and refurbishment. | ||
|---|---|---|---|
| Single Door | Double Door | Frame | |
| Maximum width | 1100mm | 2200mm | Site conditions |
| Maximum height | 2500mm | 2500mm | Site conditions |
| Jointing | Mechanical | Mechanical | Mechanical |
| Internally / externally beaded option | Yes / Possible | Yes / Possible | Yes / Possible |
| Thermal performance* | 1.6 W/m²K | 1.6 W/m²K | Site conditions |
| Glazing options | 28 – 47mm | 28 – 47mm | 28 – 32mm |
| Finishes |
Mill finish Etched and anodised on request. Polyester powder coat paint. See separate list for standard colour range available. |
||
| Single or dual colour profiles | Option | ||
| Design standards |
|
||
